The updated flagship sharpening systems will help you achieve the perfect knife sharpening even faster, more accurately, and more conveniently. Complete with Axicube-i, the first electronic protractor designed specifically for sharpening systems. Setting the angle to within 0.1° has never been so easy and convenient, the protractor is built directly into the abrasive holder. The holder itself consists of two steel guides. Specially shaped coupling provides a rigid and precise connection. No deflection and maximum precision. The rack lift has acquired a steel rack with involute (gear) gearing, which provides step-less adjustment of the sharpening angle. The slider is driven by a brass gear, and thanks to a pair of steel brass, the smooth movement of the slider is ensured. For convenience, a scale of sharpening angles is laser marked on the slider. The K03 Pro profile does not require calibration and is assembled in a couple of minutes.
Modification of the body K03 Pro has no horizontal deviations, the knife is clamped parallel to the table. A modern rack and pinion lift with a rack with involute (gear) gearing and step-less adjustment allows you to set the angle with an accuracy of 0.1 °. The body with an increased angle, due to the improved design, will allow sharpening knives in the range of working angles from 8° to 39°, which allows sharpening to a total angle of up to 78°.
The movable part is connected to the base with a dovetail, which guarantees the absolute accuracy of setting the angle. And an additional fixation screw allows you to firmly block the lift during peeling. To increase the sharpening angle, an additional lifting rod is used. Now fixing its position has become more convenient: the fixing screw can be installed on both sides of the case. The movable part is connected to the base with a dovetail, which guarantees the absolute accuracy of setting the angle. And an additional fixation screw allows you to firmly block the lift during peeling. To increase the sharpening angle, an additional lifting rod is used. Now fixing its position has become more convenient: the fixing screw can be installed on both sides of the case. The counterpart of the lift is made of a durable polymer material - polyacetal. It is a high-performance heavy-duty polymer with a density of 1.420 g/cm3. Polyacetal has excellent anti-friction properties, providing excellent smooth running of the rack and pinion lift. Black polymer with high wear and abrasion resistance. It retains its original appearance and smooth shiny surface for a long time. The slider is fastened through a dovetail connection, which eliminates the backlash of the machine during operation, which could affect the quality of the sharpening. A steel rail is responsible for the operation of the lifting mechanism. The angle measurement scale is printed on the front side of the slider and makes it possible to visually control their installation.
The unique swivel mechanism has a wide lever that makes it easy to rotate and securely auto-lock the clip frame. Thanks to the system of springs and bearings, the frame turns over without the wear of the mechanism. The body of the auto-rotation system is made of high-strength aircraft-grade aluminum with a black anodized finish.
The universal holder allows you to use any abrasive stones with the sharpener both on blanks and without blanks. The abrasive holder does not have a metal substrate, but thanks to the special geometry of the stops, it allows you to fix the abrasives as reliably as possible. The abrasive holder bar has an increased length of 694 mm, is made of steel, and has high rigidity. The holder rod is collapsible and is connected by an aluminum sleeve-coupling, with a “three-point” landing mount, which gives maximum alignment of the connection. For adjustment, the rod is equipped with a convenient lamb screw, and the connection of the rod occurs in one motion.
Included with the abrasive holder is a device for measuring the angle of sharpening - Axicube. Designed specifically for sharpening systems, the protractor is integrated into the body of the movable stop of the holder and allows you to track the parameters of the sharpening angle in real-time. Axicube has a rigid connection with the abrasive holder and is in the plane of the abrasive stone. This allows you to get the maximum accuracy of the angle in the process. Allows you to set the angle with an accuracy of 0.1 °. Axicube has a black anodized aluminum body, is water splash and dust resistant, and is resistant to vibrations, drops, and temperature extremes. Attention - charging slot is not resistant to water. It can be operated at temperatures from 0 to +40°С. Recharges with a standard micro-USB charger. Every Axicube is factory calibrated with verified measuring instruments. Before use, using a special calibration prism is given an initial reference angle. When moving the sharpener to a different surface, a new calibration using a prism is necessary.
Axicube is a patented invention. Patent No. 2768504. Axicube® is a registered trademark. The device is not intended for measurements other than sharpening; correct operation of the device is possible only in combination with Profile K03 Pro. The product is not compatible with TSPROF Kadet and TSPROF Blitz sharpeners. Correct operation of the device with other sharpening systems is not guaranteed.
Fully milled clamps are made of high-strength aircraft-grade aluminum. This type of clamp provides the greatest rigidity and stability of the device. Due to the monolithic design of the clamps, their main advantage is the increased resistance to pressure on the abrasive, which ensures the constancy of the angles at all stages of work, from peeling to finishing. When working with this type of clamp, calibration and adjustment to different shapes of knives is not required. They have a simple and convenient clamping principle (using one key), and they allow you to clamp a wide variety of knives, including knives with descents from the butt, folding, kitchen, hunting, etc.
